Air pressure type 220kw 100L Falling Type Internal Mixer / Artificial Leather Plastic Banbury Mixer

China Air pressure type 220kw 100L Falling Type Internal Mixer / Artificial Leather Plastic Banbury Mixer supplier
Air pressure type 220kw 100L Falling Type Internal Mixer / Artificial Leather Plastic Banbury Mixer supplier Air pressure type 220kw 100L Falling Type Internal Mixer / Artificial Leather Plastic Banbury Mixer supplier Air pressure type 220kw 100L Falling Type Internal Mixer / Artificial Leather Plastic Banbury Mixer supplier

Large Image :  Air pressure type 220kw 100L Falling Type Internal Mixer / Artificial Leather Plastic Banbury Mixer

Product Details:

Place of Origin: CHINA
Brand Name: FLAME
Certification: ISO9001:2000,CE
Model Number: 100L

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD 116000/set
Packaging Details: Standard Export Packing
Delivery Time: 60 working days
Payment Terms: T/T
Supply Ability: 5 sets/month
Contact Now
Detailed Product Description
Material: Cast Steel Color: Green
Rotary Speed Of Front Roll: 40r/min Rotary Speed Of Back Roll: 34r/min

100L Falling Type Plastic Mixer For Artificial Leather



Name

Plastic Mixer

Heating Way

Oil Or Steam

Type

Falling Or Internal

Feature

It is mainly used for plasticating, mixing and final mixing the stock

rotors

Chrome Plated and Alloy Hardfacing Electrodes

Material

Cast Steel

Connect Way

cardan

capacity

120-150 Kg/batch

Certificate

CE



1. Technical parameter

  • Total cubage: 100L

  • Rotary speed of front roll: 40r/min;

  • Rotary speed of back roll: 34r/min;

  • Motor power: AC 220kw/380W/50Hz;

  • Oil heating or steam heating type;

2. Main character

  • Precision roller sphere bearing;

  • Compulsory lubrication;

This machine can open the discharge door by person when the electric is off;



3. Equipment list

1  main body                                            1 group

2  press hammer and cylinder                  1 group

3  material feeding device                        1 group

4  discharge device                                  1 group

5  transmission device                              1 group

6  electric control device                           1 group

7  oil pressure and lubricate device          1 group

8  tubing                                                    1 group



Air pressure type 220kw 100L Falling Type Internal Mixer / Artificial Leather Plastic Banbury MixerAir pressure type 220kw 100L Falling Type Internal Mixer / Artificial Leather Plastic Banbury MixerAir pressure type 220kw 100L Falling Type Internal Mixer / Artificial Leather Plastic Banbury MixerAir pressure type 220kw 100L Falling Type Internal Mixer / Artificial Leather Plastic Banbury Mixer

4. Applications:

  • PVC Artificial Leather
  • PVC film
  • PVC plastic floor
  • PVC plastic sheet
  • Plastic mixer
  • Rubber mixer



5.  Main Technical Parameter:

Project Model

S-75L

S-100L

S-120L

S-160L

Working capacity of mixing chamber (L)

75

100

120

160

Rotating speed of rear rotor (r/min)

1:1.17

1:1.17

1:1.17

1:1.17

Main motor power (kw)

160

220

300

400

Pressure of compressed air (MPa)

0.6

0.6

0.6

0.6

Colling water

0.35M3/min

0.4M3/min

0.45M3/min

0.55M3/min

Heat transfer oils

45,000kcal/hr

50,000kcal/hr

6,000kcal/hr

70,000kcal/hr

Weight (t)

22

24

28

32

Overall dimensions(mm)

5100×2200×3000

5500×2300×3200

5650×2350×3300

5800×2500×3450

Connect Way

cardan



6.  Competitive Advantage:

  • PLC control system

  • Lower noise,safer mixer

  • Excellent dispersing effect

  • Best mixing chamber to get 100% mixing effect.

  • Fast Mixing,good effectivity

  • Easier Maintenance.

  • Long life.

  • No leakage.



7. Service:



  •  Oversea installation guide.

  •  Oversea test running

  •  Oversea worker training

  •  Technical support

  •  Spare parts supply supply of spare parts

  •  Technical operation support

  •  Formula and processing support



8. Option

   Two rotor mixer, the relative rotation, the material from the feed mouth clamp into the roll gap by rotor extruding and shearing, after through the roll gap above the top tied pien is divided into two parts, respectively along the chamber wall and the gap between the rotor before and after the return to roll gap above.In a week around the rotor flow, material is influenced by the shear and friction action, make rubber temperature rise sharply, lower viscosity, increased the wettability on the surface of the rubber in the compound, make good contact with rubber and compound surface.



9.  commercial terms

1. Payment: 30% by T/T as advance payment, balance(70%) by T/T before shipment

2. Lead Time: 60 days after receiving the advance payment

3. Transportation: container, simple package ( PE film, salver)

4.Warranty period: From the day of the use of the machine in the buyer’s factory:

   (1) The mechanical Parts: 12 months

   (2) The electrical Parts: 6 months

5. Installations and Commissioning

  (1) Up to date Last commissioning will have been made before shipment

  (2) Overseas Commissioning and charges

   one or two technicians will be sent to the buyer to guide the installation and commissioning of the equipment if the customer requests.

   Customers  pay the charge of our technicians.

   (1) Round-trip Airplane Ticket

   (2) Charges of transportation, accommodation and communication

   (3) The allowance for the technicians is USD 80 per day for one person.

   (4) An interpreter is needed.

6. Spare parts:

    Spare parts for one year are needed for the customers, and we suggest that customers should buy the spare parts. (Fittings list will be provided.)

7. English manual, Figuration drawing, and footing drawings are provided.
