Double beams PP Spunbond Non Woven Fabric Making Machine for massage cloth

Large Image : Double beams PP Spunbond Non Woven Fabric Making Machine for massage cloth

Product Details:

Place of Origin:	China
Brand Name:	AL
Certification:	CE,ISO9001
Model Number:	AL-1600SS,AL-2400SS,AL-3200SS

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	USD540,000~2,000,000 FOBNINGBO
Packaging Details:	Wooden case; carton
Delivery Time:	45~90 days
Payment Terms:	T/T;L/C
Supply Ability:	40sets/year

Contact Now

Detailed Product Description

High Light:

nonwoven fabric machine

non woven fabric manufacturing machine

Double beams PP Spunbond Non Woven Fabric Making Machine

1. Quick details:

1> Model AL-1600SS , AL-2400SS , AL-3200S

2> Width 1600 to 3200mm

3> Fabric GSM :10~250 g

4> Speed : 0~250m/min

5> CE ; ISO9001

2. Parts of PP Spunbond Non Woven Fabric Making Machine:

Recycle Extruder---->Main Extruder---->Filter---->Metering Pump---->Monomer Suction Device--->Spinning Box---->Quenching Air Chamber---->Stretching Device---->Web Former---->Calender---->Winder---->Slitter

3. Spun-Laid Process And Technical Flow Chart:

Additive(Recycling Off-cut Fabric)---->Raw Material---->Melting---->Filtering---->Measuring ---->Spinning---->Cooling---->Stretching---->Web Forming---->Calendering---->Winding----> Cutting---->Final Product

Double beams PP Spunbond Non Woven Fabric Making Machine for massage cloth 0

4. General Information For PP Non Woven Fabric Making Machine:

Model No.	AL-1600SS	AL-2400SS	AL-3200SS
Working Width	1600mm	2400mm	3200mm
Fabric GSM	15~250	15~250	10~250
Power Input	300KVA	350KVA	400KVA
Consumption	200KW	250KW	300KW
Annual Output	3000T	4800T	6000T
Embossing Pattern	Diamond, Oval,Cross,Line
Fineness	1.5~2.5dtex
